Landschlacht ​Primary School

Landschlacht ​Primary School

Lukas Imhof Architektur

Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer

MANUFACTURERS
Bricosol Ag

STRUCTURAL ENGINEERING
Rolf Soller Ag

PROJECT MANAGEMENT
Construct Baumanagement Gmbh

DESIGN
Lukas Imhof, Jean-brice De Bary

PROGRAM / USE / BUILDING FUNCTION
Primary School

PROJECT MANAGEMENT, PLANNING, DRAWING
Carmen Diaz-marotto Rivas

PHOTOGRAPHS
Hannes Heinzer

AREA
3500 M²

YEAR
2022

LOCATION
Landschlacht, Switzerland

CATEGORY
Schools, Extension

Landschlacht ​Primary School
© Hannes Heinzer

Text description provided by architect.

PROGRAM

Extension of an existing, partially listed school complex as a new building/extension with new surroundings.

The extension contains classrooms, group rooms, a library, a new workroom and new access to the old and new buildings.

Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer

DESCRIPTION

The existing school complex with the listed core school building, the multipurpose hall from the 1980s and a kindergarten were to be extended with additional classrooms.

We interpreted the task in such a way as to create a new spatial order on the site: a new main entrance for the entire complex with a public entrance square on the one hand, and an intimate play and learning courtyard inside the complex on the other, with the third outdoor space being redesigned as a "green schoolroom" under the mighty existing oak tree.

Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer

We are addressing the issue of sustainability with unagitated and economical "low-tech" solutions. Large areas of glazing are replaced by "sensibly" large windows with glass with a low solar control function.

A large and accessible storage mass enables passive heat storage. Night cooling and geothermal probe heating with geo-cooling regulate the indoor climate.

Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer

To ensure the best possible system separation, we decoupled components with different lifetimes and minimized interconnected component layers (no suspended ceilings, no glued-on floors, etc.).

Electrical cables were not laid in concrete, but remain accessible and traceable in a crawl space and integrated into carpentry work.

Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer

Ventilation ducts are integrated into the carpentry work - for example as a bench.

The outer wall made of single-stone masonry has no other structural layers apart from an inner and outer render.

Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer


Landschlacht ​Primary School
© Hannes Heinzer
Landschlacht ​Primary School
© Hannes Heinzer


Landschlacht ​Primary School
Section 1
Landschlacht ​Primary School
Section 2


Landschlacht ​Primary School
South-West Elevation
Landschlacht ​Primary School
North-West Elevation


Landschlacht ​Primary School
Ground Floor Plan
Landschlacht ​Primary School
1st Floor Plan
Landschlacht ​Primary School
Site Plan
