House in Port de la Selva

House in Port de la Selva
© Marià Castelló

House in Port de la Selva

Marià Castelló Martínez + José Antonio Molina

ARCHITECTS
José Antonio Molina, Marià Castelló Martínez

STRUCTURE
Think Enginyeria SLP

CONSTRUCTION MANAGEMENT
Management: José Antonio Molina, Lorena Ruzafa, Marià Castelló

DESIGN TEAM
Lorena Ruzafa, Marga Ferrer

BUILDER
Construccions Pòrfit

FACILITIES
QS Enginyeria i Associats SLP

MANUFACTURERS
Rothoblaas, ELEVATE, Bulthaup, Diabla Outdoor, Fragments d'Arquitectura, Geopannel, ICONICO, LEMA, Tres

TECHNICAL ARCHITECT
Joan Noguer

PHOTOGRAPHS
Marià Castelló

AREA
3337 ft²

YEAR
2021

LOCATION
El Port De La Selva, Spain

CATEGORY
Houses

Port de la Selva is a small coastal settlement in the northernmost part of the Costa Brava.

House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló

The intervention is located on a plot of land in the “La Tamariua” urbanization on the north slope of Puig Gros, a small promontory that surrounds and protects the town’s port.

The topography presents a pronounced slope towards the sea with abundant outcrops of “pòrfit”, a dark and very hard rock that characterizes the geology of the volcanic origin of the place.

The climatic conditions are typical of the Mediterranean climate, although sometimes they become extreme, with strong winds from the north (Tramuntana) that frequently hit the coast.

House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló

The tension between the optimal solar orientation and the deep panoramic views compresses the program of a house for a family with four children on two levels: the lower one embedded in the bedrock and the upper one, fragmented into two volumes.

This combination of strategies (embedding in the ground and volumetric division) makes it possible to reduce the apparent volume of the intervention and improve its integration into the landscape, as well as generate different patios that provide warmth, lighting, and ventilation at strategic points.

House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló

The interstices between the rocky “pòrfit” substrate and the architecture become the most lyrical moments of the proposal and where you most want to be.

While on the lower level, almost at street level, more intimate relationships with the outside are established through patios, on the upper level the two volumes open frontally to the landscape and the sea horizon.

Also at the top level more introverted relationships are generated between the volumes and the rocky substrate that surrounds them.

House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló

Thus, the glass nexus, which connects the two bodies and contains the vertical communication, acts as a screen against the wind and generates an exterior space sheltered from the prevailing wind but visually permeable towards the sea.

This in turn is capable of receiving correct sunlight during the winter months, as it is also oriented to the south.

House in Port de la Selva
© Marià Castelló

From a tectonic point of view, concrete is the predominant material both outside and inside, given that its stony nature establishes an intense dialogue with the rocky substratum of the place.

Likewise, its resistance to inclement weather (strong winds and marine environment) makes it one of the most durable options, with little maintenance and, therefore, more sustainable.

House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló

Also outside, “pòrfit” gravel from the emptying of the excavation has been used to finish the roofs and the interstitial patios between the intervention and the bedrock.

To compensate for the intrinsic qualities of concrete, oak wood has been chosen to materialize the exterior carpentry, some cladding, custom-made furniture, etc., providing the whole with warmth and harmony.

House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló


House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló


House in Port de la Selva
Gif 02
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló


House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló
House in Port de la Selva
© Marià Castelló


House in Port de la Selva
Planta subsuelo
House in Port de la Selva
Plano de sitio


House in Port de la Selva
Sección transversal 1
House in Port de la Selva
Sección transversal 2
House in Port de la Selva
Sección transversal 3
House in Port de la Selva
Sección transversal 3
House in Port de la Selva
Sección perspectiva
House in Port de la Selva
Detalle constructivo


House in Port de la Selva
Elevación sur
House in Port de la Selva
Elevación oeste
House in Port de la Selva
Elevación norte
House in Port de la Selva
Axonometría


House in Port de la Selva
Plan cubiertas
House in Port de la Selva
Planta baja


House in Port de la Selva
Maqueta 01
House in Port de la Selva
Maqueta 02
House in Port de la Selva
Maqueta 03
House in Port de la Selva
Gif 01
