mia2 ARCHITEKTUR ZT GmbH

Town House in Linz

Town House in Linz

Mia2/Architektur

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

LEAD ARCHITECTS
Sandra Gnigler, Gunar Wilhelm

MANUFACTURERS
Geberit, Duravit, Elmer , Forbo Flooring, Knauf, Röfix, Uginox

STRUCTURAL ENGINEERING
Kotlaba Ziviltechniker Gmbh

CONSTRUCTION UNIT
Simader, Baumeister Und Zimmermeister Gmbh

HEATING AND PLUMBING
Peter Bönisch Installationsges.m.b.h.

PHOTOGRAPHS
Kurt Hörbst

AREA
1275 M²

LOCATION
Linz, Austria

YEAR
2021

CATEGORY
Apartments

Town House in Linz
© Kurt Hörbst

The Town House is located in the central street Lederergasse - a livable, quiet street that connects Linz's main square, via the tobacco factory, with the port.

The existing building – its primary substance from the 16th century – has been renovated and expanded. Over a process lasting several years, first, the premises on the ground floor were converted into the company's own architect's office.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

The apartments on the 1st and 2nd floor were cleared out and renovated down to their constructive structures. In the last two years, the inventory has been supplemented with an addition.

In order to enable a gentle renovation of the existing building without major interventions, during the process of changing the development plan regarding the new story number, the position of a new entrance with a connection core, staircase and lift has been also defined.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

In this way, the characteristics of the historical substance could be preserved in the best possible way. The addition is carried out according to ecological, economic, and structural requirements in mixed construction - mostly timber construction.

As an in-house project, this construction project has always been an experimental object for us for innovative renovation methods and special solutions.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

For example, the CLAY from the excavation on the ground floor was processed into rammed earth walls and these are now being used as prefabricated load-bearing parts when the story is added.

Using wood-concrete composite technology, the several hundred-year-old wooden ceilings could be preserved and strengthened in terms of statics and building physics.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

A five-story spiral staircase was built from specially developed precast concrete elements.

The free-standing staircase is wrapped in a metal net, which is to be overgrown with kiwi and vine tendrils over the next few years.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

In order to counteract the sealing in the best possible way, we have provided the roofs of the courtyard buildings with a green roof and the areas in the courtyard have been made robustly playable with water-permeable GRP grids.

RAILINGS that were disposed of during another construction project have been re-adapted and are now finding new uses in our balcony shelf.

The wood addition shows up on the street side with a mullion and transom facade that covers several needs, such as fall protection, the fire barrier function, and the structure.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

In addition to all these ecological, economic, and formal considerations, the social and community idea was also important to us.

In addition to a LIVELY and LIVABLE townhouse with communicative balconies and courtyard areas, we also took our responsibility as a neighbor and counterpart seriously.

Balconies on the south facade and garden on the ground floor enable communication and the meeting area for workers of the office and inhabitants of the building.

Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst

The street side should be just as friendly, with a ground floor that people like to walk along. Our small bench in front of the main facade is used to rest - we are very happy about that!


Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst
Town House in Linz
© Kurt Hörbst


Town House in Linz
Town House in Linz
Town House in Linz
Town House in Linz


Town House in Linz
Town House in Linz
Town House in Linz
Site plan
Town House in Linz
Section


Town House in Linz
Diagrams
