reMix Studio 临界工作室

W(an)W(an)S(hu) House

W(an)W(an)S(hu) House
North volumes taken from the central garden. Image © Federico Ruberto

W(AN)W(AN)S(HU) HOUSE

reMIX studio

ARCHITECTS
ReMIX studio

PHOTOGRAPHS
Federico Ruberto

AREA
1100 m²

YEAR
2018

LOCATION
Beijing, China

CATEGORY
Gallery, Houses, Renovation

Text description provided by architect.

The project is an extension designed to host private residential spaces as well as spaces for a local artists community.

W(an)W(an)S(hu) House
The two extension viewed from the West side. Image © Federico Ruberto
W(an)W(an)S(hu) House
South envelope and existing building . Image © Federico Ruberto

The intervention connects and mediates the presence of two existing volumes; it grows around the two separated units generating different light conditions, fusing in a non-linear sequence the existing programs and the “new”, which comprises of creative disciplines such as sculpting, painting, pottery.

The volumes weave around in their bare materiality enveloping more private and secluded spaces, interiors that are of three types: meditation, rest and discussion.

W(an)W(an)S(hu) House
View from the South volume seen from the elevated terrace of the North volume. Image © Federico Ruberto
W(an)W(an)S(hu) House
North volume’s materials. Image © Federico Ruberto

The volumes overground are defined by layers that, keeping a calculated balance between dissolution and solidification, work mainly on one function: mediating and organizing through few formal gestures the “incalculable”: light.

The composition, texture and density of the facades result from the interpolation of three parameters: degree of reflection/refraction of direct light (artistic requirements, maximization of view from interior to exterior (living requirements, and minimization of visual permeability from exterior to interior (privacy.

W(an)W(an)S(hu) House
South volume’s materials. Image © Federico Ruberto
W(an)W(an)S(hu) House
South volume’s terrace and connection to the top level. Image © Federico Ruberto

Materials are kept to the bare minimum; anodized aluminum envelops all the new overground terraces and glass volumes, whilst rough concrete defines the underground spaces.

The program has no identifiable divisions, no internal boundaries define the newly inserted activities, which are diluted by light and transformed into programmatic gradients.

W(an)W(an)S(hu) House
From the North painting room towards the South block. Image © Federico Ruberto
W(an)W(an)S(hu) House
South volume’s terrace. Image © Federico Ruberto

For this reason each space (spatial sequence is surrounded by a continuous system, a porous envelope made by glass and several layers of a differently oriented mesh —superimposed sheets that have apertures and densities varying according to specific requirements.

This operation generates different degrees of visual permeability, reflection and ultimately privacy. The new addition appears solid in volume/color/texture if looked from the outside, but it visually vanishes when "lived" from the inside, an effect generated by the juxtaposition of differently oriented layers of stretched aluminum mesh that “opening up” or “closing down” force the eyes to see trough or not, to catch peculiar reflections according to where they are placed.

W(an)W(an)S(hu) House
Exterior ramps of the South terraces. Image © Federico Ruberto
W(an)W(an)S(hu) House
South volume’s yoga terrace and projection room. Image © Federico Ruberto

The landscape around the building [unfinished at this stage] is supposed to work formally in continuity with the architectural mass, establishing ground links between the two poles of the plot.

The material simplicity of the hardscape -wooden deck and aluminum mesh, works in conjunction with a less formally determined softscape which has set plants and groups of essences placed emphasizing the presence of water, the amount of solar irradiation, and the desired degree of privacy from the surroundings.

W(an)W(an)S(hu) House
Projection room. Image © Federico Ruberto
W(an)W(an)S(hu) House
South connection towards the top level. Image © Federico Ruberto

At the moment there is no effective presence of vegetation on the elevated terraces and on the facades, this is because time has not yet run its course.

By the end of summer we expect to be able to catch layers of vegetation expanding all around the building, growing from the elevated terraces that have embedded soil containers along their perimeters, and from the base of each metallic surface.

W(an)W(an)S(hu) House
Night view of the North volume’s South face. Image © Federico Ruberto
W(an)W(an)S(hu) House
North volumes taken from the main access . Image © Federico Ruberto

It is only a matter of time, and of weather, for the rough geometric definition of the envelope to loose itself up whilst being parasitized by the green.

Bringing such unpredictable element to fuse with the linear austerity of the intervention (to be an added layer composing the facade will not only build more interesting aesthetic effects but will help maintaining the interior cooler in the hot days of summer.

W(an)W(an)S(hu) House
South volume’s exterior envelope. Image © Federico Ruberto


W(an)W(an)S(hu) House
North volume’s materials. Image © Federico Ruberto
W(an)W(an)S(hu) House
In between the North volumes . Image © Federico Ruberto
W(an)W(an)S(hu) House
Mesh reflections. Image © Federico Ruberto
W(an)W(an)S(hu) House
Underground meditation room. Image © Federico Ruberto
W(an)W(an)S(hu) House
South volume’s yoga terrace. Image © Federico Ruberto
W(an)W(an)S(hu) House
Two layers metal mesh. Image © Federico Ruberto
W(an)W(an)S(hu) House
South top terrace. Image © Federico Ruberto
W(an)W(an)S(hu) House
Night view of the South volume’s South face . Image © Federico Ruberto


W(an)W(an)S(hu) House
Presentation model
W(an)W(an)S(hu) House
Models, first (wood) and second option (Perspex)


W(an)W(an)S(hu) House
Top view and elevation
W(an)W(an)S(hu) House
Sections and diagrams of the intervention
