Harbour Club
Courtesy of LEVS architecten

Harbour Club

LEVS architecten

CATEGORY
Restaurants & Bars, Mixed Use Architecture, Residential Architecture

LOCATION
Amsterdam, The Netherlands

AREA
10200 m²

PHOTOGRAPHS
Beemflights

YEAR
2021

DESIGN
Adriaan Mout, Jurriaan Van Stigt, Marianne Loof, Christiaan Schuit, Surya Steijlen

MANUFACTURERS
Solarlux, Aldowa, Kawneer, Balqoon, Constar, Fek Metaal

ACOUSTIC ADVISOR
Level Acoustics & Vibration

RESTAURANT AND THEATRE
3,200 m²

CONTRACTOR
Bouwbedrijf M.j. De Nijs B.v, Bouwbedrijf M.j. De Nijs En Zonen Bv

BUILDING PHYSICS ADVISOR
Nieman-valk Technisch Adviesbureau

PROJECT TEAM
Daan Goedhart, Mark Gijsbers, Eerde Van Leeuwen

CLIENT
Amvest

CONSTRUCTION ADVISOR
Pieters Bouwtechniek

INSTALLATION ADVISOR
Ingenieursburo Linssen

Project Harbour Club in Amsterdam’s quickly developing eastern neighborhood Cruquiuseiland is finished. The complex volume is a collage of old and new buildings and an unconventional program.

Harbour Club
Courtesy of LEVS architecten
Harbour Club
Courtesy of LEVS architecten

There are the left-over industry-sized wine silos that have been turned into rooftop villas. Then there is the club at the heart of the new building, sound-proofed and structurally isolated to such an extent that it was possible to build apartments directly above it.

Finally, there is the original building from 1901, neatly encapsulated by the new building and topped up with a green roof.

Harbour Club
© BeemFlights
Harbour Club
Courtesy of LEVS architecten

The three white, round volumes on top of the highest roof cannot be missed. Visible from across the harbor and the Amsterdam ring road, they are architectural icons for this industrial harbor turned residential neighborhood.

Once they stored bulk wine for the Dutch market. Now they are fully equipped homes with three stories and panorama windows, standing on a private wooden and green deck with views over the city.

No small technical challenge, the silos had to be cleared of toxic chemical traces and installed by lifting them over a row of adult trees.

Harbour Club
Courtesy of LEVS architecten
Harbour Club
Courtesy of LEVS architecten

Interesting detail: the silos were insulated using the same method as used in the numerous houseboats down below in the harbor.

Both nonetheless were outweighed by the environmental and cultural value of preserving this material and characteristic object.

A core challenge of the plan was the incorporation of a sizeable event venue directly underneath 81 much-needed apartments for young starters.

To solve it, the venue was made effective as a stand-alone building, with its own foundation.

Harbour Club
Courtesy of LEVS architecten
Harbour Club
Courtesy of LEVS architecten

The surrounding apartment building floats, as it were, above this box on long overarching beams. Nowhere do the two buildings touch, the in-between spaces filled with absorptive material.

Entrances to the restaurant and club lie on one side of the building, those to the apartments on the other.

Harbour Club is a contemporary answer, characterized by unconventional solutions. We have restored an existing building from 1901 and added a high-density residential building and a soundproof event space.

The result exudes the same playfulness and eagerness with which LEVS architecten made and worked out the design for Amvest.

Harbour Club
Courtesy of LEVS architecten
Harbour Club
Courtesy of LEVS architecten

The old building’s roof was topped with a second, green roof for water retention, heat adsorption, and sound barrier between restaurant and residents.

A prominent street-side façade separates the two and highlights the boundary between the two functions with a metal perforation artwork: a long composite panorama of images from the distant past to present-day life along the harbor of Cruquiuseiland.

Harbour Club is a multi-level challenge: technically, programmatically, and architecturally. The combined necessities of affordable densification, restoration of monuments as well as climate mitigation and adaptation need to be addressed simultaneously.

The Harbourfront has become a social boulevard shared by the restaurant’s terrace and pedestrians in an equal manner.

Harbour Club
Courtesy of LEVS architecten


Harbour Club
Harbour Club
Harbour Club
Harbour Club
Harbour Club
