Magazzino Italian Ar
MAGAZZINO ITALIAN AR
MQ Architecture
ARCHITECTS
MQ Architecture
AREA
2300 m²
YEAR
2016
PHOTOGRAPHS
javier callejas
MANUFACTURERS
Kalwall®, Airfloor system, Duro-Last, Saint-Gobain
PROJECT LEADER
Jesus Aparicio Alfaro
ARCHITECT
Rocio Calzado Lopez
STRUCTURAL ENGINEER
Michael Carr, PE
M E P
CES-Consulting Engineering Services
CIVIL ENGINEER
Badey & Watson Surveying & Engineering, P.C.
LIGHTNING
MAP Design Studio
GRAPHIC DESIGN
Waterhouse Cifuentes Design
COST ESTIMATING CONSULTANT
Stuart-Lynn Company, Inc.
DESIGN
Miguel Quismondo, AIA
LOCATION
United states
Text description provided by architect.
Magazzino Italian Art is a private initiative conceived by Nancy Olnick and Giorgio Spanu to house their collection of post-war Italian art. The commission consisted in a full renovation of an existing 11,000 square-foot building and an additional 14,000 square feet of new construction. The existing L-shaped structure was erected in 1964 as a distribution center for dairy products and surrounded by loading docks and canopies.
The new space needed a taller clearance, since some of the collection’s pieces were large, as well as highly controlled natural light. The starting approach was simple: the existing L-shaped building could be completed into a rectangle with a central courtyard.
Consequently, it would establish a dialogue between the new and existing building; the natural light helps stress precisely that: the existing building works with the specific, solid light coming from the skylights aligned with the main pathways through the building, whereas the expansion proposes a uniform and faint light that makes the most of the whole. In both spaces, we have tried maximize the flexibility of artificial light by means of track lighting that crosses the lower interior cordons of the joist.
The existing structure opens up to the courtyard while the addition only opens a panoramic window to the Wetlands. Additionally, the juxtaposition of the two volumes makes the central courtyard become a virtual room, an extension of the lobby, while the reflecting pool that regularizes its geometry facilitates the transition between the existing building and the addition.
The flow was reduced to a simple circle in order to make the visitors follow an intuitive sequence of rooms; to keep guests from being weighed down by the burst of art, the spaces open to the exterior to help people rest their eyes throughout the tour.
The “in situ” formwork concrete wall, shaped with phenol-treated wood panels, makes up the skin of the new container; the roof cover is solved by using a simple structure involving metal gable trusses, and the white interior walls create a neutral backdrop for enjoying art.
This new structure regularized the arrival and the surrounding gardens, allowing the visitors to discover the entrance by contrast of volumes and materials. This idea allowed us to propose an independent structure that would run parallel to the longer part of the existing building and link both structures by means of two glass connectors, thus stressing the lightness.
The constant traffic on State Route 9, which runs next to the slope where the project is located, forced the project to turn away from the road, and the attempt to make the interior environment as quiet as possible required a detached concrete shed with building systems along the parking area.
Magazzino, which means warehouse in Italian, attempts to pay homage to its name and the Arte Povera collection which it houses. While the artists worked with elements considered to be poor, low-quality, or readily available, we wanted to pursue this philosophy by using simple components and building techniques.
