PORTO METRO

Eduardo Souto de Moura

CATEGORY
Metro Station

LOCATION
Porto, Portugal

YEAR
2005

 COLLABORATORS
Arq. André Campos, Arq. Ricardo Tedim, Arq. Eduardo Carrilho, Arq. Joana Pinho, José Carlos Mariano, Arq. Bernardo Durão, Arq. Diogo Crespo, Arq. Manuel Pais Vieira, Arq. Nuno Flores, Arq. Nuno Lopes, Arq. Tiago Coelho, Arq. Tiago Figueiredo, Arq. Eduardo Pereira, Pedro Chimeno Soares da Costa – Gabinete de Projectos

STRUCTURES
CENOR – Projectos de Engenharia, Lda.; COBA – Consultores para Obras, Barragens e Planeamento, S.A.; CJC – Engenharia e Projectos, Lda.; VIA PONTE – Projectos e Consultoria de Engenharia, Lda.

CONSTRUCTION
Normetro ACE

MAINTENANCE
Transdev

ENGINEERING
Semaly

CIVIL CONSTRUCTION
Transmetro (Soares da Costa, Somague, Impregilo)

HYDRAULICS
FASE – Estudos e Projectos, S.A.

CONSTRUCTION
Normetro ACE

ELECTROMECHANICAL
Balfour Beatty Rail

SIGNAGE
Bombardier Transportation

The surface light rail glides smoothly to the surface on two lanes of steel, without making much noise.

Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves

The implementation of the rails is imposed by a quota system, according to strict rules, with no room for subjective considerations.

The surface light rail glides smoothly to the surface on two lanes of steel, without making much noise.

Steel rails must be incorporated into the streets (in an emergency, firefighters must be able to pass). Materials can range from granite cubes, asphalt mat or grass carpet.

Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves

For acoustic reasons, the rails are supported on a floating slab, padded with foam rubber, which receives the steel parts.

The implementation of this system requires the demolition of the streets and, consequently, the entire infrastructure.

New sewerage, storm water, gas, electricity, telephone, cable TV, fiber optics and sometimes piping, have to live with the Metro system to be built - multi-tube boxes of 20 x 20 meters.

Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves

But the problem of the metro on the surface, is not only the surface, we must look to the sky, airlines and lighting. These can be suspended from a central "post" or two side posts.

When the width of the street does not allow the system, airlines are suspended by wires from façade to façade.

The problem is usually the "NUAGE" glass facades or brick of 7 cm on the outer wall.

Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves

We work from center to center (the metro channel is always inflexible) and the remainder is distributed to other vehicles parked where appropriate, and routes to reach the thresholds.

We can make transitions of materials, changes in slope, but the thresholds are "sacred", like playing on the shoulder of a stranger.

Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves

From shoulder to shoulder we exchange flooring, textures, walks, guides, anti-guides, light poles, trees. It's not that we want to change the geography, but the "Metro forces".

When there are difficulties, we use the "Transmetro" the "Normetro" which in turn communicates with the metro, the Chamber, the parish council, residents and merchants.

Porto Metro
© Luis Ferreira Alves
Porto Metro
© Luis Ferreira Alves

After being approved "for execution", the streets that intersect and expand yielding roundabouts, squares, left places, small squares, squares with trees, parking and, why not, "Boulevards" - Avenida da República: Gaia / Matosinhos begin to emerge.

Without this as our vocation, the Metro builds places, nooks, combinations cities, it draws the Metropolis - Gaia, Porto, Matosinhos, Maia, Trofa, Vila do Conde, Povoa de Varzim, Gondomar and more.

Porto Metro
© Luis Ferreira Alves

Cities do not change by political decree, but by the appearance of the systems necessary for their survival and development.

So it was with the Romans, on two routes that crossed, they designed the Cardus and Decomanus, and in the center, the Forum.

Porto Metro
© Luis Ferreira Alves

So it was in the Middle Ages, the Forum was the Cathedral Square, built with the stones of the demolished temple.

It was so in the Baroque, with the design of radiocentric axes, this Cathedral was linked to the doors of the Wall.

It was so in the Neo-Classic, gates were demolished or redesigned and expanded for linking the roads and became squares surrounded by convents.

It was so in the nineteenth century with the railway, some convents became stations (San Benito).

Porto Metro
© Luis Ferreira Alves
Porto Metro
Section

It was so in the twentieth century, with the light rail (Matosinhos / Trinidad).

It will be so in the twenty-first century in which the light rail must be integrated into a planned system for new geography (quite improvised) that cannot be postponed.

Porto Metro
Section
Porto Metro
Section 2

"The country is small and we are few ..." (Jose Cardoso Pires), but I think we will succeed.


Porto Metro
Section 3
Porto Metro
Upper level floor plan


Porto Metro
Site Plan
Porto Metro
Ground Floor Plan
Porto Metro
Roof Plan


Porto Metro
East Facade
Porto Metro
South Facade
Porto Metro
North Facade
