HOUSING NEUFRANKENGASSE

Em2n

ARCHITECTS
Em2n

MANUFACTURERS
Pamax

PHOTOGRAPHS
Simon Menges

AREA
5800.0 m²

YEAR
2008

LOCATION
Zurich, Switzerland

CATEGORY
Housing

Text description provided by architect.

The project is developed out of its exciting location between two extremes: the inner city Kreis 5 (District 5) and a large area of railway tracks.

Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges

This expansiveness of this “lake of a different kind” gives the place its exceptional quality.

The layered structure of the building reacts in both plan and section to the external circumstances.

Bedrooms and loggias face south and look onto the quiet courtyard.

Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges

Entrance halls, wet rooms and cloakrooms are centrally positioned. Living and dining areas profit from the expansive nature of the area of tracks.

Depending on their position in the building some of them are double-height, the apartments at the lower levels profit from an added spatial value.

Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges

Generously-dimensioned loggias connect the spacious living areas to the courtyard. Access to the building and the three staircases is from Langstrasse and from the courtyard through a plinth level that receives daylight.

The architectural expression presents the internal structure. Towards the wide area of railway tracks a number of large window openings permeate the regularity of the façade.

Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges

The calm façade facing the more intimate courtyard makes repetitive use of openings of the same size. Here the staggered positioning of the balconies suggests something of the animated interior.


Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges
Housing Neufrankengasse
© Simon Menges


Housing Neufrankengasse
Ground Floor Plan
Housing Neufrankengasse
First Floor Plan
Housing Neufrankengasse
Second Floor Plan
Housing Neufrankengasse
Third Floor Plan
Housing Neufrankengasse
Fourth Floor Plan
Housing Neufrankengasse
Attic Floor Plan
Housing Neufrankengasse
First Basement
Housing Neufrankengasse
Second Basement


Housing Neufrankengasse
Section
Housing Neufrankengasse
Section


Housing Neufrankengasse
East Elevation
Housing Neufrankengasse
West Elevation
Housing Neufrankengasse
South Elevation
Housing Neufrankengasse
North Elevation


Housing Neufrankengasse
Situation
