JAQUET DROZ SWISS WATCH MANUFACTORY

Atelier Oï

ARCHITECTS
Atelier Oï

CATEGORY
Industrial Architecture, Offices

LOCATION
La Chaux-de-fonds, Switzerland

PHOTOGRAPHS
Yves André

AREA
630.0 m²

YEAR
2010

CONSTRUCTION MANAGEMENT
Ortech Sàrl

HVAC & SANITARY INGENEER
Röschi + Partner AG

STRUCTURAL ENGINEER
AJS ingénieurs civils SA

TEXTE
Nicole Grumser

PROJECT MANAGEMENT
The Swatch Group Immeubles SA

TECHNICAL OFFICE IN ELECTRICITY
Bms SA, Avry

Jaquet Droz Swiss Watch Manufactory
© Yves Andre
Jaquet Droz Swiss Watch Manufactory
© Yves Andre

Text description provided by architect.

In order to bring out the concept of a sculptural object, North and South facades are made of “structural glazing”.

Jaquet Droz Swiss Watch Manufactory
© Yves Andre
Jaquet Droz Swiss Watch Manufactory
© Yves Andre

That choice enables totally flush external surfaces without any visible façade profiles.

The mirror glazing provides the building with an elegant and precious character but also contributes to the high level of comfort of the workspaces.

Jaquet Droz Swiss Watch Manufactory
© Yves Andre
Jaquet Droz Swiss Watch Manufactory
© Yves Andre

In fair weather conditions, the nature reflects on the facades, and under outdoor lower light levels, the indoor craft activity becomes the highlighted scene.

GLAZING COMPOSITION : 6MM-THICK OUTER PANE

Silver Antelio float glass, tempered on outside face ,with silkscreen printed edges

Jaquet Droz Swiss Watch Manufactory
© Yves Andre
Jaquet Droz Swiss Watch Manufactory
© Yves Andre

22MM GLAZING SPACE

Argon gas and black aluminium spacers.

6MM-THICK INNER PANE

Thermally toughened, heat-soak treated glass with low-emissivity coating

Jaquet Droz Swiss Watch Manufactory
© Yves Andre
Jaquet Droz Swiss Watch Manufactory
© Yves Andre

That double glazing both insures solar control - by reducing solar gain - and enhances thermal insulation. Antelio outer panes have a metallic coating applied on the glass through a pyrolysis process which gives them a mirror shine. The spandrels are made of tempered glass.


Jaquet Droz Swiss Watch Manufactory
Site Plan
Jaquet Droz Swiss Watch Manufactory
Floor Plan


Jaquet Droz Swiss Watch Manufactory
Section 1
Jaquet Droz Swiss Watch Manufactory
Section 2
