BARCODE COMPLEX

A1Architecture

ARCHITECTS
A1Architecture

LOCATION
Hormozgan Province, Kish, Hormoz Sq, Iran

CATEGORY
Office Buildings

ARCHITECT IN CHARGE
Amir Afghan

PROJECT YEAR
2017

PHOTOGRAPHS
Deed Studio

MANUFACTURERS
Knauf, Lorenzo, AlocoBand

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

Text description provided by architect.

The strategy lead to creating a shell that covers the entire volume and provide a symbolic and unique character while also controls the lighting and the view.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

The distance of the shell and glass has established a green interface between internal and external environment which often have a significant temperature and humidity difference.

On the other hand, this has led to different and exclusive experiment for each of administrative units which all share common plans, parallel layouts and similar sizes.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

Expensive value of the land and commercial function of it lead to designing a plain and pure structure to maximize the usage of land.

Boosting visibility and noticeability of valuable commercial flats on the ground and on the same time maximizing the organic light and view of very small administrative units on higher levels, resulted in pure glass structure.

Later, searching for a solution to encounter the harsh climate of the region along with looking for method of unitizing the project, the native architecture of the Persian Gulf guided us to the double shell structure which the natives use to control the heat and light of sun through shadows of the outer layer and air circulation in the space between.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

Then the second shell was designed inspired form reticular shells of natives and next was adding the green texture in the space between to catalyze the softening process.

Recreating the connection of inside and outside of the building, as well as generating a distinguishable difference in similar flat units, conduced to invention of an interface which become axis of design strategy for this project.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

In fact there are many companies (both national and international) who need to have small office in Kish to operate their business there.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

On the same time there are some businesses in the island that are prestigious though do not need much of space for their operation.

However, due to our studies there is serious lack of small offices in Kish.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio

Adding the facts of being independent (in terms of services, parking, ...) and prestigious, made the issue even more significant.

That is how we came with the idea of small, independent and prestigious administrative offices.

Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio


Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio
Barcode Complex
© Deed Studio


Barcode Complex
Diagram
Barcode Complex
Diagram
Barcode Complex
Functional Diagram


Barcode Complex
Section
Barcode Complex
Model
Barcode Complex
Scheme
Barcode Complex
Sections


Barcode Complex
Ground Floor Plan / 1st Floor Plan
Barcode Complex
2 and 3 Level Plan
Barcode Complex
Site and -1 Level Plan
