Amnon Bar Or - Tal Gazit Architects Ltd.

Lodzia Factory House

LODZIA FACTORY HOUSE

Amnon Bar Or - Tal Gazit Architects

Lodzia Factory House
© Amnon Bar Or - Tal Gazit Architects
Lodzia Factory House
© Avi Levi

ARCHITECTS
Amnon Bar Or - Tal Gazit Architects

LOCATION
Nahmani Street 43, Tel Aviv, Israel

LEAD ARCHITECTS
Amnon Bar Or, Amnon Bar Or – Tal Gazit Architects Ltd.

PROJECT YEAR
2018

CITY
Tel Aviv-Yafo

AREA
2448.0 m2

COUNTRY
Israel

INTERIOR DESING
Orly Shrem Architects Ltd.

MANUFACTURERS
Golmat Group, Noga Tiles, Shagrawi-Leibovich Building Ltd.

CATEGORY
Renovation

PHOTOGRAPHS
Avi Levi, Eliasaf Robinson Collection, Yehudit Shweb, meitar koll, Nirit Yaron

BUILDER
Shagrawi-Leibovich Building Ltd.

PROJECT MANAGEMENT AND SUPERVISION
Margolin Bros. Engineering & Consulting Ltd.

CLIENT
Arava Vineyards Ltd.

CONSTRUCTION ENGINEER
Jacob-Yuval Achbert structural engineers Ltd.

Text description provided by architect.

The Lodzia factory building, built in 1923 is the only industrial building of its kind in Israel, built in modern technology integrating 19th century European nostalgic references, while searching for a new Jewish - Zionist style.

The building has remained a landmark to this very day. Its reddish color and unique shape, is different from the rest of the buildings in the city. The old Factory was built by Polish immigrants from Lodz, imitating the industrial typology that was familiar in their home town.

Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi

Strict conservation restrictions posed a real planning challenge in effort to reuse the old abandoned factory structure into contemporary residential apartments.

The new residential program fits the neighborhood’s primary designation, thus allowing new residential development without losing the building's historical, urban, architectural and cultural values.

Any additional areas essential for the new program could be done only as unseen additions and only underground.

This led to the planning of two basements under the whole lot.

Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi

In order to build the basements under the historic building, a temporary support system was planned for the existing structure, using hundreds of steel poles embracing the existing walls and foundations.

This method enabled to disconnect the original foundations and conduct the digging works.

Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi

The building was monitored with electronic sensors until placed on new foundations.

The building’s facades were accurately preserved.

The factory was built in two stages – the first wing in 1924 using red bricks and the second in 1929 with white ones.

During the preservation works, the red bricks found on the site were sliced into two and were used as cladding wherever those were missing in the first wing.

Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi

The white colored bricks which were scattered around the building were collected and reused in the preservation works.

Since the original building had no blinds, the widows’ opening direction was changed in order to allow the installation of interior shading solutions for privacy and light regulation.

Instead of adding window bars to the openings on the ground floor, a concealed alarm system was installed inside the window and door frames.

In the collective memory, the building's roof is perceived with red “Marseille” roof tiles that where common in Palestine during the 1920’s.

Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi

In the drawings found in the city archive of the original building from 1924, a two-toned diamond shaped tile pattern was planned.

Historical research led us to restore the roof in two-toned zinc tiles: light gray (new zinc) and dark gray (aged zinc) - as a tribute to the historical building. A balcony was designed inside the roof volume with unique planting details, serving the apartment on the upper floor.

Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Amnon Bar Or - Tal Gazit Architects

The two iron staircases on the Eastern Facade, one for each wing, were the only original access between the floors of the old factory.

These staircases were carefully dismantled and treated by a master craftsman. One staircase was converted into emergency stairs while the second was reused as two balconies.

Lodzia Factory House
© Amnon Bar Or - Tal Gazit Architects
Lodzia Factory House
© Eliasaf Robinson Collection

In order to preserve the building’s authenticity, the two building stages were emphasized while adapting the building to contemporary needs.

The project was completed in the summer of 2018 and was populated by the owners soon after.

Lodzia Factory House
© Eliasaf Robinson Collection


Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Avi Levi
Lodzia Factory House
© Amnon Bar Or - Tal Gazit Architects
Lodzia Factory House
© Yehudil Shweb


Lodzia Factory House
Southern Facade
Lodzia Factory House
Eastern Facade
Lodzia Factory House
Eastern Facade


Lodzia Factory House
Section 01
Lodzia Factory House
Section 02
Lodzia Factory House
Section 03
Lodzia Factory House
Section 04
